60W 10Gbps PoE Injector Protect Indoor Wall-mounted BT PoE injector Input 100-240Vac Output 55Vdc 1100mA 10G date rates
from
$86.15
Ex Tax: $86.15
- Stock: In Stock
- Model: JE00006497
- Weight: 5.80g
- SKU: JE00006497
Products Sold: 0
Product Views: 102
Ask a Question About This Product
- Description
Designed for the PoE++ powered 60W PoE Powered Devices (PDs), such as IP Cameras, wireless APs, Microwave radios, IoT applications, door locks, displays, POS, and information kiosks, It supports 10/100/1000Mbps/10GBps of data rates. Fully comply with IEEE802.3bt and remains compatible with any IEEE802.3af/at compliant devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non-PoE device.
Enclosed in an IP40 fire retardant plastic case, designed for indoor installation with Wall-mounted. It operates with a wide input voltage of 100-240 VAC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables.Can be extended with the PT-PEX-01G-OT(Outdoor or Indoor PoE Extender).
| Parameter | Description |
| Key Features | PoE++ ,IEEE802.3BT |
| High-speed 10G data rates | |
| Power for 802.11ax Wave 2 Access Points, Pan-Tilt-Zoom (PTZ) Cameras and Video-Phones | |
| Ports condition | LAN Port*1, AC Input Port*1, PoE Output Port*1 |
| Regulatory Compliance | IEEE802.3bt |
| RoHS Compliance | |
| WEEE Compliance | |
| Pass-Through Data Rates | 10GBit/s |
| Output | pin Assignment and Polarity: |
| 4/5(+),7/8(-)and 3/6(+),1/2(-) | |
| Output Power Voltage:55Vdc User | |
| Port Power:60W Guarantteen | |
| Input | AC Input Voltage: 100-240 Vac |
| Frequency: 50/60Hz Typ. | |
| AC Input Current:1.5A | |
| Working Environment | Operating Temperature: 0℃ to 40℃ |
| Operating Humidity: 20% to 80%, non-condensation | |
| Storage Temperature: -20℃ to 70℃ | |
| Storage Humidity: 10% to 90%, non-condensation | |
| Operating Altitude: up to 5000meters | |
| AC Surge Protection | Line-Earth 1.2/50us (8/20us): 2KV |
| Line-Line 1.2/50us (8/20us): 1KV | |
| Mechanical Characteristics | Case: Plastic |
| Color: Black | |
| Mounting: Wall-mounted | |
| IP Rated: IP40 | |
| Connectors: Shielded RJ-45*2 | |
| Size: 145.51mm X 65.8mm X 33.5mm | |
| Weight: 255g（8.99oz） | |
| LED Indicator | Power Indicator : Green |
| PoE Load Indicator : Green @≤30W | |
| Blue @＞30W≤60W | |
| Safety Approvals | cUL/UL/FCC/CE |
