30W Procet Indoor AT PoE injector single port midspan Injector 55Vdc 550mA
from
$33.39
Ex Tax: $33.39
- Stock: In Stock
- Model: SAUTO-1-M-FB-S-IP40-RO
- Weight: 5.80g
- SKU: SAUTO-1-M-FB-S-IP40-RO
Products Sold: 0
Product Views: 199
Ask a Question About This Product
- Description
Designed for the PoE+ powered 30W PoE Powered Devices (PDs), such as IP Cameras, wireless APs, Microwave radios, IoT applications, door locks, displays, POS, and information kiosks, It supports 10/100/1000Mbps of data rates. Fully comply with IEEE802.3at and remains compatible with any IEEE802.3af compliant devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non-PoE device.
Enclosed in an IP40 fire retardant plastic case, designed for indoor installation with Wall-mounted. It operates with a wide input voltage of 100-240 VAC, 50 or 60 Hz.
| Parameter | Description |
| Key Features | Wall-mounted |
| Ports condition | LAN Port*1, AC Input Port*1, PoE Output Port*1 |
| Regulatory Compliance | IEEE802.3at |
| RoHS Compliance | |
| WEEE Compliance | |
| Pass Through Data Rates | 10/100/1000 Mbps |
| Output | Pin Assignment and Polarity: |
| 4/5 (+), 7/8 (–) | |
| Output Power Voltage: 55Vdc | |
| User Port Power: 30W Guaranteen | |
| Input | AC Input Voltage: 100-240 Vac |
| Frequency: 47 to 63Hz (50/60Hz Typ.) | |
| AC Input Current: 1A | |
| Working Environment | Operating Temperature: 0℃ to 40℃ |
| Operating Humidity: 20% to 80%, non-condensation | |
| Storage Temperature: -20℃ to 70℃ | |
| Storage Humidity: 10% to 90%, non-condensation | |
| Operating Altitude: up to 2000meters | |
| PoE Surge Protection | Protected line: 1,2,3,4,5,6,7,8 |
| Common mode surge protection(10/700us): 6KV | |
| Differential mode surge protection (10/700us): 1.5KV | |
| AC Surge Protection | Line-Earth 1.2/50us (8/20us): 2KV |
| Line-Line 1.2/50us (8/20us): 1KV | |
| Mechanical Characteristics | Case: Plastic |
| Color: Black | |
| Mounting: Wall-mounted | |
| IP Rated: IP40 | |
| Connectors: Shielded RJ-45*2 | |
| Size: 140mmX 63mmX 33mm | |
| Weight: 205g（7.23oz） | |
| LED Indicator | Power Indicator: Green |
| PoE Load Indicator: Green |
